PoE Splitter, 802.3af/at/Passive PoE IN, 802.3af & 48V Passive GigE PoE OUT, 32W
$98.95
Customize
Store Qty
15 Features
802.3at PoE input, 802.3af and Passive PoE outputs Gigabit compatible Extended temperature range: -40 to +70°C Short circuit and over current protection Applications
Power Non-PoE Devices from a PoE Network Deploy Remote IoT & Sensor Equipment Security & Surveillance Installations Wireless Networking Industrial and Commercial Control Systems Edge Devices in Distributed Networks Short Description
Tycon Power® PoE Splitter, 802.3af/at/Passive PoE input, 802.3af & 48V Passive Gigabit Ethernet PoE output, 32W. Long Description
The POE-SPLT-48G-VUB is an active splitter which accepts an 802.3at Mode A/B or passive PoE (2 or 4 pair) input and provides two PoE outputs. Output 1 is an 802.3af Mode B PoE output with Data and PoE. Output 2 is a 48V Passive PoE Mode B output with PoE only, no data. The splitter is designed to supply power and data to one device and power only to the second device. It is Gigabit compatible providing speeds to 1000MB. There are various protections for short circuit, overload and low voltage disconnect. Technical Links
Spec Sheet http://www.tyconsystems.com//specsheets/POE-SPLT-48G-VUB_Splitter__Spec_Sheet.pdf User Guide https://www.tyconsystems.com/usermanuals/8000053_POE-SPLT-48G-VUB_Install_Guide.pdf KnowledgeBase
https://tyconsystemsinc.zohodesk.com/portal/en/kb/power-over-ethernet-poe
